UHMWPE Transfer Chute & Hopper Liner Panels

Transfer chute liners are the largest single wear-part order most mining and bulk-handling sites place — 50 to 800 panels at a time, sized 1250 × 1250 mm or 2000 × 1000 mm, in 10 – 50 mm UHMWPE depending on the abrasiveness of the material being conveyed. We pre-drill every panel to your hole pattern before shipping so site installation is bolt-up only. For the most abrasive duties (iron ore primary transfer towers) we offer a composite version: UHMWPE wear face mechanically interlocked to a Q235 carbon-steel back plate for dimensional rigidity.

Get Quote WhatsApp

UHMWPE Transfer Chute & Hopper Liner Panels

Specifications & MOQ

All SKUs are made-to-order from our own UHMWPE / HDPE / nylon production line. Send your DWG / DXF / PDF / STEP — we quote within 24 hours, MOQ from 1 piece.

Product	MOQ	Material	Image
UHMWPE Transfer Chute Liner (panels with countersunk holes)	20 panels	UHMWPE GUR1020 (virgin)
Composite Wear Liner (UHMWPE wear face + steel back)	10 panels	UHMWPE wear face + Q235 carbon steel back

Technical Specifications

Material Options	UHMWPE GUR1020 (standard) / Composite UHMWPE-on-steel
Standard Panel Sizes	1000 × 1000 / 1250 × 1250 / 2000 × 1000 / 2000 × 1500 mm
Thickness Range	10 / 15 / 20 / 25 / 30 / 40 / 50 mm
Color	Green (UV) / Black
Hole Pattern	Customer drawing — typically M12 / M16 countersunk on 200 / 300 / 400 mm grid
Edge Treatment	Square cut (default) / chamfered / tongue-and-groove for joint sealing
Composite Steel Back Thickness	6 / 8 / 10 mm Q235 carbon steel
Lifespan vs Mild Steel	5× to 10× in iron ore / coal transfer applications

Application Cases

Mining Transfer Tower Wear Liner Retrofit

How a copper concentrator replaced 240 m² of steel chute liner with UHMWPE in one shutdown.

Read case →

Cement Plant Belt Scraper Blade Cycle

Polyurethane primary + UHMWPE secondary scraper combo for a 1200 mm cement plant raw mix conveyor.

Read case →

Frequently Asked Questions

Can you ship 800 panels in one container?

Yes — 1250 × 1250 × 25 mm UHMWPE panels stack 60 panels per pallet (~1.5 t per pallet). One 40 HQ container fits 18 – 20 pallets, so 1,000 – 1,200 panels per container is typical.

Do you supply the bolts and washers?

We can include 316 stainless M16 countersunk bolts, washers and nylock nuts as a packed kit — please request when inquiring. Otherwise hardware is sourced locally.

Can you machine pocket-and-key for stitched panel assembly?

Yes — tongue-and-groove edges for sealed wet-coal chutes, or pocket-and-key for non-bolted dry-aggregate chutes. Add to drawing notes.
