Impact Bars (UHMWPE wear face + rubber base)

Impact bars sit under the conveyor belt at receiving points (chute discharge, stockpile feed, primary crusher discharge). Steel bars chew up belts; UHMWPE bars let the belt slide and absorb the falling material's energy through the bonded rubber base. Our standard configuration is a 25 mm UHMWPE wear face bonded to a Shore A 65 SBR rubber base, sized 1250 × 100 × 75 mm with M16 mounting slots — but every bar dimension is made-to-order from your drawing.

Get Quote WhatsApp

Impact Bars (UHMWPE wear face + rubber base)

Specifications & MOQ

All SKUs are made-to-order from our own UHMWPE / HDPE / nylon production line. Send your DWG / DXF / PDF / STEP — we quote within 24 hours, MOQ from 1 piece.

Product	MOQ	Material
UHMWPE Impact Bar (top wear face, rubber-bonded base)	10 pcs	UHMWPE wear top + SBR rubber base bonded
Solid UHMWPE Impact Bar (no rubber, all-plastic)	10 pcs	100% UHMWPE GUR1020 (virgin)
POM Impact Bar (high-load, low-friction)	10 pcs	POM-C (Acetal copolymer) virgin

Technical Specifications

Wear Face Material	UHMWPE GUR1020 (virgin)
Wear Face Thickness	20 / 25 / 30 / 40 mm (replaceable)
Base Material Options	SBR rubber Shore A 65 / SBR Shore A 70 / Solid UHMWPE / POM-C
Standard Length	1000 / 1250 / 1500 mm
Standard Width	75 / 100 / 125 mm
Standard Height (with rubber)	60 / 75 / 100 / 125 mm
Mounting	Pre-drilled M16 / M20 slots (5 / 7 / 9 holes per bar)
Service Temperature	−40 °C to +80 °C with rubber base; −200 °C to +80 °C all-UHMWPE
Replacement Interval	3 – 7 years depending on tonnage and abrasiveness

Application Cases

Mining Transfer Tower Wear Liner Retrofit

How a copper concentrator replaced 240 m² of steel chute liner with UHMWPE in one shutdown.

Read case →

Limestone Quarry Primary Feed Impact Bar Replacement

Replacing 18 m of steel impact bars with UHMWPE-on-rubber bars at a limestone quarry primary feed conveyor.

Read case →

Frequently Asked Questions

How is the UHMWPE wear face bonded to the rubber base?

Mechanical interlock — the UHMWPE face has dovetail grooves on the underside that the rubber is vulcanized into. No glue. The bond outlasts the wear face.

Can I get the bars in custom lengths?

Yes — every length from 500 mm to 2400 mm is made-to-order. Send the bar dimensions and the bolt pattern; we quote per piece.

Will solid UHMWPE bars (no rubber) work for my transfer point?

Solid UHMWPE bars work well for medium-impact zones (≤ 1.5 m drop height, < 50 mm material lump). For high-impact zones (heavy ore, > 2 m drops), the rubber base makes a meaningful difference in belt life — we recommend the bonded version.
